Description The ALFA 400 TAB is the evolution of CNC welding technology, designed for precision, repeatability, and Industry 4.0 integration. Managed through a 10” Android tablet (1920 × 1200 resolution), the system combines advanced automation with an intuitive interface. Capabilities Bends up to Ø 400 mm (16” IPS) Wyes, tees, crosses up to Ø 315 mm (12” IPS) Welding of fittings or molded bends with thin clamps Key Features Automatic welding cycle with minimal operator intervention Continuous hardware/software communication for accurate process control Graphical cycle monitoring with operator validation at each stage Automatic management of heating plate, pipe joining, and resets in case of pressure drops Customizable welding parameters via tablet interface (Setup – Welding – Options) Integrated data logging and detailed welding reports Composition Machine body with two carriages (one hydraulic-driven) Tablet control panel with built-in memory Automatic horizontal sliding heating plate Milling cutter with recirculating ball slideways and electronic soft start Upper cylinder for thick pipes or high-pressure applications Available in 230 V or 400 V Standard Supply Machine body with tablet Heating plate Milling cutter Upper cylinder service tools Elbow jaws Ø 400 mm with inserts Ø 90–355 mm Optional Accessories Tee/cross jaws Ø 315 mm with inserts Ø 90–280 mm Wye jaws Ø 315 mm with inserts Ø 90–280 mm Right/left special jaws Ø 400 mm with inserts Ø 90–355 mm Flange neck tool
